X-Solar

Photovoltaic plants monitoring

Summary, you can:

• Acquire energetic and economic data for an easy management
• Acquire data and consult them directly on the X-Solar instrument’s
  display
• Apply to fiscal meters already present until 2 optical interfaces (Produced Energy and Purchased Energy/Delivered)
• Detect the direction of energetic flows for an exact account of the same
• Insert into the system a combined sensor of irradiation and panel temperature, even equipped by the option for transmitting data via-radio
• Genarate alarm state (lack of production in presence of Irradiation, Inverter anomaly, or when a QE Inveter’s magneto-thermal
  switch is off)
• Have an instrument equipped by an Ethernet interface
• Have the functionality of the system with a Web interface

Running on Ethernet Network

The instrument has an Ethernet interface which, when used, allows an high extension of the system functionalities, through a Web interface and a system for sending e-mail, by means of additional servers. Web interface makes available a consultation of the described data by means of a normal Web browser (recommended Firefox, Opera, Chrome, Safari) and a Personal Computer, a tablet or a netbook, connected to the local network via-cable or wi-fi.

Data available on the web: instantaneous values

• Power Generated (production assignment) (kW)
• Consumption power of the generation plant (production during absorption) (kW)
• Power delivered to the electrical network (exchange sale) (kW)
• Power absorbed by the electrical network (exchange during absorption) (kW)
• Power used (production + exchange) (kW)
• Irradiation (W/m2)
• Panel temperature (°C)
• Power expected with current Irradiation and Temperature (kW)
• Status concerning the exchange on the network (absorption, delivery or null)
• Status concerning the Inverter production (full production, degraded production or off)

Data available on the web: historicized values

The values are available in the following periods:

• Current day
• Previous day
• Current month
• Previous month
• Current year, previous years (until 10)
• Total value from starting date

Available values:

• Energy Generated ( production assignment ) (kW)
• Consumption energy of the generation plant (production during absorption) (kW)
• Energy delivered to the electrical network (exchange sale) (kWh)
• Energy absorbed by the electrical network (exchange during absorption) (kWh)
• Energy used (production + exchange) (kWh)
• Remuneration energy produced (€)
• Remuneration Energy delivered to the electrical network (€)
• Cost of energy drawn form the electrical network (the calculation is made on the average cost kWh) (€)
• Cost of used energy (production + exchange) (€)

Option with combined sensor Irradiation-panel temperature:

• Expected Energy (kWh)

Graphics relative to: energy produced, energy delivered, energy purchased, energy used:

• Graphic showing the daily production on a hourly basis within the current day and previous day
• Graphic showing the monthly production on a daily basis within the last 10 years

Working in stand-alone

In this modality the instrument isn’t connected to Ethernet network, data acquired are available directly through X-Solar instrument’s display.

Alarms

When the system is coupled with the combined Irradiance and temperature sensor, it can generate alarm state corresponding to low performance of the plant (due, for example, to shadows of trees grown in this side after the plant was installed, or a dirt on the panels) or absence of production in presence of solar irradiance (due, for example, to a fault in the inverter or if the magneto-thermal switch is off); the first type of alarm is considered on daily basis on the data of the previous day, the second is evaluated in real-time, with a signal delayed by one hour for avoiding false alarms due to temporary shadings. The alarm is showed on the instrument’s display and on two special contacts (digital outputs).

Basic configuration for monitoring the Produced Energy meter:

• n.1 X-Solar
• n.1 wired Photoreceivers for reading the LEDs on the Produced Energy meter and Exchanged Energy meter

Options:

• Sensor for Solar Irradiance and Temperature PT100 by GSL-IT-DA
• Sensor for Solar Irradiance and Temperature PT100 by GSL-IT-W Radio transmitter module
• Radio receiver GSL-C module for sensors of Solar Irradiance and Temperature (4 channels); range: 250 meters in open-field
• Wired Photoreceivers for reading the LEDs on the Produced and Exchanged Energy meters, reach 250 meters in open field
• n.1 Openable Current transformer, internal diameter 24 mm, for discriminating the direction of the energy flow in the Produced energy meter. This installation was planned in order to eliminate the energy recording due to self consumption in the Inverters and in the insulating transformers
• n.1 wired Photoreceivers for reading the LEDs on the Exchanged Energy meters

Additional Services

By inserting into provision these additional services, it’s possible to:

• Send the alarms through e-mail service and, eventually, daily e-mail with production data
• Get a backup of the daily data: in this way, if a fault in X-solar occurs, the historical data aren’t lost
• See and consult the Web page even outside the Customer’s local network
• See and consult data coming from more plants (for installers and maintainers)
